| 特性概要 ( General Specifications ) |
| 绕组连接方式 ( Winding Type ) | 星形 ( Star connection) |
| 霍尔分布角度 ( Hall Effect Angle ) | 120度电角度 ( Electrical Angle of 120 degree) |
| 径向间隙 ( Radial Play ) | 0.02mm |
| 轴向间隙 ( Axial Play ) | 0.14mm |
| 最大径向负载 ( Max radial force ) | 115N 距法兰10mm ( 10mm From the flange) |
| 最大轴向负载 ( Max axial force ) | 45N |
| 介电强度 ( Dielectric Strength ) | 600VAC/1S |
| 绝缘电阻 ( Insulation Resistance ) | 100MΩ, 500VDC |
| 环境温度 ( Ambient Temperature ) | -20°C ~ +50°C |
| 绝缘等级 (Insulation Class) | Class B |
